GE UR8HH - Multilin UR Module, Advanced Protection and Monitoring Solution

2024-12-31 BY jonson

UR8HH|1A/5A ground CT and 3-1A/5A phase CT are available for relays

General Electric Multilin’s UR-8HH is a CT/VT module designed to be installed in the general purpose relay family. It provides the relay with 1A/5A ground CT and 3-1A/5A phase CT, which allows the relay to narrow the rated current and rated voltage to a single value, enabling the relay to monitor these system conditions and output data for the user to view. This data can then be used for protection system functions performed by the relays themselves. This data can be viewed via the relay’s LCD display or more efficiently via Multilin’s EnerVista UR software program.

EnerVista UR also allows for efficient configuration of the Settings associated with CT/VT modules, allowing for highly customized schemes to meet the unique needs of each user’s system. In addition, EnerVista UR’s simplified design enables users to easily view data in a beautiful, well-laid out user interface. Viewpoint UR Engineer from EnerVista also has a drag-and-drop environment that allows for quick debugging of relays and related modules.

Potential buyers who pay attention to installation times will see that GE designed its universal relay family with scalability in mind. The panel of the device can be unfolded (on enhanced and basic models of relays) to allow access to the module bays, and Multilin provides plenty of information and diagrams on proper module wiring in its various product manuals.
GE UR8HH - Multilin UR Module, Advanced Protection and Monitoring Solution

About UR-8HH
What is the role of UR-8HH in the universal relay T35?
The T35 is a basic transformer protection system capable of protecting the main power transformer and the five feeders downstream of the main power transformer. The T35 can be operated automatically or user-defined using the amplitude reference winding selection. In either case, the T35 provides phase-shift compensation, CT ratio matching, and even allows the operator to eliminate zero-sequence currents.
What are the components of UR Series Multilin universal relays?
The UR-8HH is one of the many components of general-purpose Multilin relays such as the T35 base transformer protection system. UR General purpose relay GE Multilin contains CT/VT modules such as UR-8HH, it also contains a digital input/output module, a power supply (sometimes dual power supply), a sensor input/output module, a central processing unit (CPU), relay-to-relay communication with the communication switch, and a sensor input/output module. And an IEC process bus. Each of these components can be specified with different ordering options to tailor precise functionality to the type of UR Series universal relay required for the final application. In this way, universal relays provide the end user with a comprehensive, customized, advanced technical solution.

2024-12-31 BY jonson

IN Industry trends

UR8FH|A CT/VT module Designed for installation in a general purpose relay series

General Electric Multilin’s UR-8FH is a CT/VT module designed to be installed in the general purpose relay family. It provides the relay with 3-1A/5A phase current transformer, 1A/5A ground current transformer and four voltage transformer terminals. Current transformers and voltage transformers are able to reduce current and voltage to manageable levels for relay monitoring and control, and are necessary to generate important data for relays.

CT/VT modules can use voltage or contact inputs on channels 1 to 4 inclusive or channels 5 to 8 inclusive. The UR manual provides more information on proper relay connections, pointing out important details such as how channels 1 and 5 are connected to phase A, and channels 2 and 6 are connected equally to B. The manual also provides the user with full warnings and notifications, for example, for relay terminals with nominal currents of 1 A or 5 A, connections to the CT must match the secondary rating of the connected CT lest the user wish to cause system damage. In summary, before starting Relay connection, users must read the Universal Relay manual carefully.
GE UR8FH Multilin Firmware PLC Temperature Modules, Advanced Industrial Control Solutions

Frequently Asked Questions about UR-8FH
Does the UR-8FH protect against ground failure situations when integrated into GE Multilin universal relay systems?
The UR-8FH is described as a CT/VT with standard 4CT/4VT. It has no sensitive grounding function, so it can protect universal relays on ground systems classified as high impedance. The modules with this capability are UR-8G, UR-8J, UR-8M, and UR-8R ordering numbers. These references are newer CT/VT generation. There are also two older CT/VT modules (UR-8B and UR-8D) with sensitive ground fault protection. For example, standard models with 4CT/4VT capabilities do have typical capacities of up to 24 analog current transformers and voltage transformers, as described in all CT/VT modules included in various general-purpose relays. In addition to CT/VT modules, universal relays are equipped with sensor I/O modules. This provides the UR with a DCmA card or RTD to monitor flow, wind speed, temperature, vibration, or pressure. The analog output can also be used to connect the UR to an external PLC or other user interface device. The universal relay also features a digital I/O module containing up to 96 contact inputs and 64 contact outputs.

2024-12-31 BY jonson

IN Industry trends

UR6UH|When the digital I/O module is installed in the UR unit

General Electric Multilin’s UR-6UH is a digital I/O module that, when installed in a general-purpose relay, is capable of controlling and monitoring various auxiliary devices. This particular version of the module provides 6 A (unmonitored) outputs and 4 digital inputs. Potential buyers looking to purchase a model that includes monitoring capabilities should consult any general relay manual (located on the AX Control website) to better understand module options.

Due to the modular design of GE Multilin’s universal relay family, installing the UR-6UH module is easy. These modules feature a plug-and-play design that allows users to simply swap out old modules for new ones, providing fast uptime for all system upgrades. Once the module is properly installed in the universal relay, the user can begin to configure the module process manually via Multilin’s industry-leading EnerVista UR software or via keyboard and LCD.

The digital I/O capabilities of Multilin’s UR-6UH eliminate the need for analog inputs and outputs, offering many advantages over more traditional analog equivalents. Digital data processing is more cost-effective than analog data processing, reducing the pressure on users over time. In addition, digital data generates less electrical noise, contributing to smoother system function.
GE UR6UH Digital I/O Module for Auxiliary Equipment Control and Monitoring

Frequently Asked Questions about UR-6UH
What does the order code breakdown of the T60 universal relay mean for UR-6UH in the universal Multilin relay?
Let’s take a general purpose relay of the following model: T60-G03-ACH-F8H-H6M-MXX-PXX-UXX-WXX. To understand what each alphanumeric option means and what modules are included in this particular universal relay, you must consider Table 2-4 in the product manual, which breaks down the T60 ordering code for this GE Multilin universal relay. The skeleton order code is T60-***-***-F**-H**-M**-P**-U**-W/X**. Each * represents a variable point in the model number. This allows the end user to select a specific hardware module, such as the CPU, or in this case, a digital I/O module into a generic relay at a specific location. In some cases, * also indicates whether software options are included or not necessarily tangible. If we look at the digital input/output section in the order code detail, we will notice that the underlying digital I/O module can specify a two-digit ordering option in the missing (asterisk) position after the H, M, P, U, or W Spaces. Numeric I/O modules have a two-digit code beginning with a 4 or 6. If we look back at the part number used as an example, we can notice that the H position is followed by a 6M. Therefore, the UR-6M digital I/O module is integrated into this position of the universal T60 relay. Just find XX in the model number, which means there is no module at that location.

2024-12-31 BY jonson

IN Industry trends

UR6EH|Provides digital inputs and outputs for intersystem communication

General Electric Multilin’s UR-6EH, a module for upgrading or replacing the current module in the general purpose relay family, is a digital I/O module. This module provides digital inputs and outputs to the relay, enabling it to communicate with devices in a given power system. This particular module provides 4 Form C outputs and 8 contact inputs for the relay. The Type C digital output is SDPT (single-pole double-throw), allowing switching between normally open (NO) and normally closed (NC) contacts.

Wiring instructions related to the digital I/O function can be found in any general purpose relay user manual. These manuals also provide graphics that give a deeper insight into the wiring process, thus simplifying the job for users. The user manual also includes information related to modifying Settings that affect the UR-6EH module and its functions, so it is useful to refer to any general relay manual for a number of reasons.
Bentley Nevada 178850-00 Equipment Monitor Module - Precision, Reliability, Industrial Control

Users may question which relays in the general purpose series this module is effective for; This digital I/O module is an excellent choice for any relay in the system with relays that can communicate devices in real time.

Frequently Asked Questions about UR-6EH
What is the function of the General Electric Multilin UR-6EH digital I/O module in the UR series?
The Multilin UR-6EH digital I/O input/output module is used to provide contact input or contact output for general purpose relays in the UR series of general purpose relays. These input and output contacts are useful for Multilin universal relays in order to control and monitor equipment within substations or equipment that handles protection functions. Each digital I/O can be distinguished from other Multilin I/O digital models by the type of protection card included in the module. These cards can be classified as Form A, Form C, SSR (solid state relay) or fast Form C.

2024-12-31 BY jonson

IN Industry trends

UR6DH|The relay provides digital contacts

Ge Multilin’s UR-6DH is a digital I/O module with 16 contact inputs for units in the general purpose relay family that can replace current modules or provide new functionality for a given system. This digital I/O module allows relays to communicate with devices in the power system without expensive hard wiring.

The communication and parameters collected by the UR-6DH module can be better connected using GE Multilin’s flagship EnerVista UR software program, which provides a vastly improved user interface over the simple keyboard and LCD approach. EnerVista provides Viewpoint Monitoring and Viewpoint Maintenance tools to easily edit Settings related to digital I/O communication and module functionality.
GE UR6DH UR6-DH Digital I/O Control Module: Industrial Automation Solutions

This particular module contains only the Form C contact; Before buying this model, users should make sure they don’t need a Form-A or a fast Form-C. Similar digital I/O modules in this series offer A combination of Form A and Form C (or fast Form C) contacts, providing greater variability to the system, so potential buyers should consider their system needs before making a decision.
Frequently Asked Questions about UR-6DH
What is the digital I/O in the GE Multilin UR series of universal relays, such as the Multiln GE digital I/O module UR-6DH with ordering option 6D?
GE Multilin UR-6DH Digital I/O Input/Output The UR Series Universal relay module is a specific type of digital I/O module in the UR series universal relays. Unique universal relays for different application ranges. Some, such as the Multilin L60 Line Phase comparison system, provide protection for lines and cables with different voltage characteristics. Others, such as the B30 bus differential system, provide impedance bias bus differential protection for the feeder. Regardless of the specific type of general-purpose relay and the specific end application, most, if not all, general-purpose relays include digital I/O modules to provide a general-purpose relay with variable contact input and contact output. Different digital I/O modules have models that specify the order option for the module and thus the specific types of contact outputs and inputs that the module can provide: general purpose relays and wider system applications.

2024-12-31 BY jonson

IN Industry trends

UR6CH|Digital I/O module|By providing digital input and output

Ge’s UR-6CH is a digital I/O module that enables UR relays to communicate with auxiliary devices by providing digital inputs and outputs. This particular unit provides eight C-type digital outputs. The Type C digital output is a single-pole double-throw (SPDT) contact, indicating that there is a common point connected to a normally closed contact (NC) and a normally open contact (NO). Form-C can switch between these two outputs, so it is often referred to as a “transition” contact.

The Universal relay family was built with scalability in mind, providing a hinged panel that allows access to the internal module bays for easy installation and upgrades. While the enhanced model and the normal model differ slightly in accessing the module bays, both units provide a relatively simple entry point for hardware modifications.

Potential buyers should ensure that the module they purchase is suitable for their power system needs, as other digital I/O relays in the same family offer different contact forms and functions. The series also offers devices with trip rated A-contacts, solid-state relay contacts or A, C and SSR combinations. Solid state output modules provide fast tripping, high current breaking capability and fast reset time, making them ideal for direct tripping applications.
GE-FANUC UR6CH Digital I/O Module - Industrial Automation Solutions

Frequently Asked questions about UR-6CH
What are the advantages of integrating digital I/O modules into general-purpose relay Multilin GE systems such as UR-6CH?
The digital I/O characteristics allow the universal relay to obtain contact inputs and contact outputs in order to control and monitor auxiliary devices that may be part of the application-specific protection application of the Universal Multiiln relay. Depending on the ordering options for the digital I/O modules included in the universal relay and the number included, the universal relay can have up to 96 contact inputs (rated at 250 volts) and up to 64 contact outputs. There are different types of GE Multilin digital I/O modules, which determine how many inputs and outputs each I/O module has, and which type of input or output a general purpose relay (UR) can use. For example, the UR-6CH has a 6C ordering option. This means that the output provided by this particular digital I/O module is eight Form-C outputs. If multiple such digital I/O modules are found in a particular relay, it increases the number of Form C outputs that a general-purpose relay can use for a particular end application.

2024-12-31 BY jonson

IN Industry trends

UR6AH|Digital I/O module

Modular construction: common hardware, reduced stock of spareparts, plug & play modules for maintenance cost savings andsimplification
Proven flexibility and customization capabilities make UR/URPlusdevices suitable to retrofit almost any kind of legacy P&c schemeLarge HMl and annunciator panels provide local monitoring &control capabilities, and backup the substation HMlPhasor Measurement Unit lsynchrophasor) according to llEEE diameter C37.118 (2011) and lEc8 61850-90-5 directly streamed from yourprotective dewce
Three ethernet ports enable purpose specific LAN support thateliminates latency effect of heavy traffic protocols on missioncritical communication services
GE UR6AH Digital I/O Module - Industrial Control, 200 Characters or Less
Embedded lEEE 1588 time synchronization protocol supporteliminates dedicated lRlG-8 wiring requirements for P&C devicesComplete lEC 61850 Process Bus solution provides resourceoptimization and minimizes total P&c life cycle costsIncrease network availability by reducing failover time to zerothrough lEC 62439-3 “PRP support
CyberSentry’ provides high-end cyber security aligned toindustry standards and services |NERC® ClP, based, AAA, Radius.RBAC,Syslog)
Enhanced CT’yT module diagnostics verify analog signal integrityusing an advanced algorithm, ensuring reliabilityReduces system event analysis effort with the support ofembedded high-end and extended recording functionality

Protection, control, monitoring and supervision of power assetsacross generation,transmission, distribution, substation andindustrial systems
Utility substation and industrial plant automationDigital fault recording and Sequence of Event ($OE) recording
