GE IS200TBCIS2CCD Contact Input Termination Board

2025-01-03 BY jonson

IS200TBCIS2CCD|Contact input terminal board

As mentioned above, the IS200TBCIS2C printed circuit board was originally manufactured by GE Industrial Systems for use in its Mark VI series turbine control systems and turbine control system components. This IS200TBCIS2C printed circuit board, or PCB for short, is more specifically defined as a contact input end board by its original specification manual introductory function product description, and actually exists as a modified version of the previously developed Mark VI family of products; A single Class C functional product revision IS200TBCIS2 is added to the parent printed circuit board. Although there does not appear to be a product-centric IS200TBCIS2C instruction manual available on the Internet for research purposes, Edge instruction manual materials can help develop this IS200TBCIS2C product page. Combine functional IS200TBCIS2C product numbering with a thorough and technical person-led visual inspection of the IS200TBCIS2C PCB equipment itself.

Hardware tips and specifications

The IS200TBCIS2C contact input endboard is probably best understood as a purchase option when considering the various hardware components included and the intended functionality of the IS200TBCIS2C printed circuit board in the larger Mark VI series components. As specified in the original manual materials, the IS200TBCIS2C PCB is capable of accepting a total of 24 dry contact inputs, making it a key component addition to many Mark VI components that require terminal connectors. The power supply for these dry contact inputs above comes from a floating power supply in the turbine control assembly, and each dry contact input is optically isolated and sampled at the frame rate, taking into account the control function. The contact input voltage detected by the dry contact input of the IS200TBCIS2C terminal module is fanned out to three separate VME board frames by using the three marked plugs of the IS200TBCIS2C PCB. The IS200TBCIS2C device has the honor of being part of the Mark VI family of Turbine control Systems, one of the final iterations of the Mark product family developed by GE to introduce patented and highly regarded Speedtronic control system technology into its many different functional products.
GE IS200TBCIS2CCD Contact Input Termination Board

Now that some of the perceptual capabilities of this TBCI abbreviated Mark VI family of products have been described, some unique hardware components can be put in context to achieve this claimed functionality. For starters, as mentioned earlier, this IS200TBCIS2C contact input terminal board does have three plugs; Plugs for the JR1, JS1, and JT1 labels are connected to three separate J3 label plugs in the VCCC contact input board assembly. In addition to the various plugs provided with the IS200TBCIS2C module, the TBCI PCB uses a total of six field contacts; Each filter is equipped with its own noise suppression filter. It should be noted that the IS200TBCIS2C contact input terminal board is also compatible with the VCRC module, which exists as a single-slot alternative to the VCCC contact input board described above. All of the above hardware components unique to the IS200TBCIS2C contact input terminal board should be relatively well protected, given the special style of PCB protective coating offered by GE Industrial Systems products. This conformal PCB coating can be found when performing IS200TBCIS2C functional product number segmentation, resulting in other valuable information, Includes the normal assembly version of this PCB, domestic manufacturing, TBCI functional acronym, Group 2 Mark VI Series grouping and its single Class C functional product revision.

2025-01-03 BY jonson

IN Industry trends

IS200ISBBG2AAB|Printed circuit board

The IS200ISBBG2AAB printed circuit board was originally manufactured by GE Industrial Systems, a shell company of industry leader General Electric that manufactures its EX2100 line of excitation control Systems. This product exists as a revised version of the original IS200ISBBG2 mother printed circuit board; It has been modified by including two Level A feature revisions and a single Level B illustration revision. Such a printed circuit board or PCB may be defined in more detail as an InSync bus bypass board, as specified in the originally manufactured instruction manual material for such board.

Hardware tips and specifications

Before delving into the various hardware components and specifications that make this IS200ISBBG2AAB InSync bus bypass board unique, it is important to understand the true intended functionality of this product. Unfortunately, this PCB is defined in the original EX2100 series manual material and is only defined as an InSync bus bypass board, as any other defining material regarding the functionality of this product does not appear to be available online. Having said that, a great deal of information about the IS200ISBBG2AAB board module is readily available and can be accessed through a careful visual inspection of the part and an explanation of its personalized GE product number.
GE IS200ISBBG2AAB - InSync Bus Bypass PCB for Mark VI Excitation Control Systems

Upon beginning a visual inspection of this IS200ISBBG2AAB PCB, one component that immediately stands out is that it contains four fairly large reinforcing screw supports that appear to be contained within the component of the IS200ISBBG2AAB InSync bus bypass board for installation purposes. However, these are not the only mounting hardware components included in this bypass board assembly, as at least three factory boreholes are drilled into the substrate of this product. Some of the other more obvious hardware components included in the assembly of this ISBB abbreviated model include its large, center-aligned female ports and center-grouped voltage limiting resistors and capacitors.

As the analysis of the IS200ISBBG2AAB personalized product number reveals, all of the above hardware components that are critical to the functionality of the IS200ISBBG2AAB InSync bus bypass board should be well protected under a plain PCB coating. Some of the other specifications revealed by this method include its original manufacturer location in Salem, Virginia, its normal assembly style, its ISBB functional acronym, its Group 2 EX2100 series grouping, and its triple revision history.

FAQ about IS200ISBBG2AAB
Why is the ISBB acronym for IS200ISBBG2AAB printed circuit board classified as a functional acronym?

The ISBB acronym for the IS200ISBBG2AAB model, although a convenient shorthand for the IS200ISBBG2AAB board, also describes the function of this model as an InSync bus bypass.
What factory printed labels are available on the IS200ISBBG2AAB PCB substrate?

The IS200ISBBG2AAB PCB features a range of standard factory labels, including the IS200ISBBG2AAB product number, a printed General Electric logo, and a range of naming labels corresponding to its individual hardware components.
Are the three major revisions of this product considered backward compatible?

Nooooo. While the Grade A Feature Revision 2 of this product is backward compatible with the similarly rated Feature Revision 1, the third revision used by this product is classified as a draft revision and is therefore not backward compatible with any existing feature revisions.

2025-01-03 BY jonson

IN Industry trends

IS200STCIH6AED| DIN rail contact terminal plate

IS200STCIH6A DIN-RAIL Contact Terminal Board Equipment Which part of the Product number discloses Group 6 for DIN IS200STCIH6A DIN-RAIL Contact Terminal Board equipment?

As you may have guessed, the unit’s H6 Series group label is responsible for the Group 6 Mark VI Series classification of IS200STCIH6A DIN Rail contact terminal boards.
Why does A single Class A revision of this IS200STCIH6A DIN Rail contact terminal board device work?

This revised version of the IS200STCIH6A DIN Rail Contact Terminal Board product is functional in that it focuses solely on improving the basic performance specifications and overall functional quality of the IS200STCIH6A DIN Rail Contact terminal Board device.
About IS200STCIH6A
The IS200STCIH6A is a DIN rail contact terminal board for GE Mark VI series turbine control systems. The Mark VI fan control system family of IS200STCIH6A DIN Rail contact terminal board devices has a specific set of possible functional product applications in popular and GE compatible control and management systems for automatic drive components for gas, steam and wind turbines. It must be emphasized that this is a comprehensive functional upgrade to the previously established industry standard similar to the full extended product family title in the Mark V turbine control System family, as the Mark VI series adds more possible functional applications for alternative energy based wind turbines in steam and natural gas applications. This was made possible early on with the introduction of the basic Mark V. This IS200STCIH6A DIN Rail contact terminal board product is covered by warranty upon purchase of AX.
GE IS200STCIH6AED Control Circuit Board, Specialized for Industrial Control Applications

Hardware tips and specifications

The IS200STCIH6A is a printed circuit board (PCB) with many different components. On the left and right sides of the board are two large nickel-sized factory drill holes. There are also two factory drilled reinforcement terminal holes in the lower left and right corners of the board. Next to the bottom hole are two terminal strips with numerical markings. The top is labeled 1-51 and contains only odd numbers, while the bottom is labeled 2-52 and contains all even numbers. The top center edge of the board has an RS-232 37-pin female port. The board’s part number label is located in the lower right corner of the board, between the corner and the plant drill hole. There is a white 3-pin jumper just above the top terminal board on the left side of the board. The PCB also contains 2 transistors, 91 resistors, 27 diodes and 24 capacitors. This IS200STCIH6A DIN rail contact terminal board device is not actually a General Electric product originally designed for its specific intended role as a Mark VI turbine control system family of functional products. This is true because it must be considered A single Class A functional product revision of the IS200STCIH6 parent DIN rail contact terminal board, especially one that does not utilize this IS200STCIH6A DIN rail contact terminal board device.

IS200STCIH6A is a PCB and should be handled with care. Anti-static procedures should be implemented to prevent any type of damage to the board due to the build-up and release of static electricity. The board should be kept in an anti-static bag or box until it can be installed. When installing the IS200STCIH6A, wear an ESD wrist strap.

2025-01-03 BY jonson

IN Industry trends

IS200TVBAH2ACC|Vibrate input terminal board

The IS200TVBAH2A is a printed circuit board developed for General Electric’s Mark VIe Speedtronic family of turbine control systems. This PCB can be more clearly defined as a vibration input terminal board. This type of PCB is regarded as a revised product; It exists as a modified version of the original IS200TVCAH2 printed circuit board. This IS200TVBAH2A printed circuit board, or PCB for short, belongs to the Mark VIe family, as you might have guessed from its full extended family name alone, and has a specific set of applications in popular and GE compatible management and control systems for gas, steam and even wind turbine automatic drive components. The IS200TVBAH2A PCB’s Mark VIe series is one of the final GE Mark series developed to incorporate patented Speedtronic control system technology into its diverse range of products. This improves the current automation industrial market effectiveness of the larger Mark VIe series of IS200TVBAH2A products. The IS200TVBAH2A board, perhaps more commonly referred to by its industry-renowned functional acronym TVBA, provides a direct interface for multiple types of probes, while also providing signal suppression and EMI protection for each individual input signal. This model is available for repair and replacement, right on the AX Control.

Hardware tips and specifications

The IS200TVBAH2A vibration input terminal board utilizes a range of unique and interesting hardware specifications. For starters, it’s important to acknowledge that this model of printed circuit board, like any Mark VIe system PCB, does not use a traditionally compatible RKPS power supply. Instead, the IS200TVBAH2A is powered by a 28 V supply from multiple sources. No external power supply is provided for this 28 V voltage, as the IS200TVBAH2A model must maintain exactly the same functionality as the Mark VI TVIB board. Additional TVIB board similarity for the IS200TVBAH2A is provided by the inclusion of three detachable daughter boards;
GE IS200TVBAH2ACC: High-Performance Automation Controller Module
Capable of converting +28 V voltage to -28 V voltage. All negative voltage power supplies supplied to the IS200TVBAH2A shall be contained in these subboards. While the IS200TVBAH2A does have some interesting features and functional components similar to the TVIB board; It distinguishes itself by a series of additional components. The overall assembly of the IS200TVBAH2A vibration input terminal board includes:

Two terminals
14 sensor inputs are connected to the terminal
A total of 24 terminals
The shielded end connects to the contact
Series of 11 plugs for Bently-Nevada data
A 37-pin connector
Additional buffer output to enhance connections outside of 37 pins
And many more important components
All components listed above, as well as those available on the IS200TVBAH2A vibration input terminal board substrate, should be well protected under the conformal PCB coating of this PCB, although much thinner than other conventional PCB coatings; Make the PCB protection layer more thorough and complete.

2025-01-03 BY jonson

IN Industry trends

IS200VAICH1DAB|Analog input/output card

The IS200VAICH1DAB model has multiple sensors/transmitters; What do they do, or are they powered by?

The transmitter/sensor on the IS200VAICH1DAB can be powered by a 24 VDC control system power supply or can be powered independently. They are used to monitor each output on the VAIC board; If the command of the Mark VI processor does not clear the fault immediately, the suicide relay on the model will disconnect the corresponding output.
What exactly is the IS200VAICH1DAB model?

The IS200VAICH1DAB model is an analog input/output board. It is used to accept up to 20 inputs and control up to 4 outputs with two converters, A/D and D/A, signal conditioning and an analog multiplexer.
About IS200VAICH1DAB
As mentioned above, this GE IS200VAICH1DAB printed circuit board product was originally designed and manufactured specifically for placement in GE Products’ Mark VI family of turbine control systems. The Mark VI series contains this IS200VAICH1DAB PCB product, referred to as the Mark VI Series, specifically for a range of possible and intended product applications in the control and management systems of GE compatible gas, steam and wind turbine automation drive components. This must be classified as a significant advance in terms of functionality over the previous industry standard Mark V turbine control system family (almost identical to the full extended product family name), as the Mark V series was developed for a more restricted set of possible functional applications to exist in functional environments based on gas turbines and steam turbines. This IS200VAICH1DAB PCB is covered by our AX Control PCB warranty after purchase.

Hardware tips and specifications

The IS200VAICH1DAB model is manufactured by General Electric as an analog input/output board for Mark V systems in TMR or simplex applications. When used in a TMR system configuration, the input signals on the connected terminal boards (TBAIH1C or STAI boards) are fanned out to three VME racks T, R, and S, each containing a VAIC board. The output signal on the VAIC board will be driven by a proprietary circuit, using all available VAIC boards to generate the required current. If any IS200VAICH1DAB model on the VME rack fails, the faulty VAIC model will be removed from the output and the remaining VAIC boards can continue to provide the correct current. When the model is used in a simplex configuration, the connected terminal boards will provide the input to one of the VAIC models and all the current to the output. The original VME rach-built analog input/output board manufactured for GE’s Mark VI family of turbine control systems must actually be considered the IS200VAICH1 parent product with the same full functional description, as it does not have three important revisions of this IS200VAICH1DAB printed circuit board.

During the operation of the IS200VAICH1DAB model, it will control 4 analog outputs and accept up to 20 analog inputs. The model has an analog multiplexer, A/D converter, D/A converter and signal conditioning. This model has two analog inputs, ±1 mA or 4-20 mA, which can be selected via a jumper on the included terminal board. The analog output circuit is divided; Two outputs can be configured to be 0-200 mA or 4-20 mA, and the other outputs are only 4-20 mA. Both the input and output of the IS200VAICH1DAB model contain high suppression circuits to prevent high-frequency noise and surges. In this case, the IS200VAICH1DAB device benefits from its GE manufacturing because of the presence of IS200VAICH1DAB instruction manual materials, some of which have been stored in our handy manual TAB. One such material stipulates that each individual output or input in the normal assembly of an IS200VAICH1DAB product has its own corresponding factory printed naming label. Some of the individual IS200VAICH1DAB board analog inputs and outputs include:

A total of 16 ±10 V DC /±5 V DC /4-20 mA analog inputs
A total of four 4-20 mA/± 1 mA analog inputs
Two analog outputs totaling 0-20/0-200 mA
Two 0-20 mA analog outputs

2025-01-03 BY jonson

IN Industry trends

IS200VCRCH1BBC|Discrete input/output board

IS200VCRCH1BBC is a General Electric circuit board assembly. The PCB is manufactured as part of the Mark VI system, the fifth Speedtronic system released by GE for gas turbine and steam turbine management. The Speedtronic series began with the release of the MKI in the 1960s and continued through the MKVI and MKVIe in the 2000s. Mark VI includes a variety of features such as software and hardware diagnostic tools, alarm management tools, Ethernet communication capabilities, time synchronization for HMI and controls, and fully programmable software maintenance tools. The Mark VI turbine control system family must be defined as a significant functional upgrade over the previous industry standard Mark V series, which has the same full extended series name, Because it adds to the already established gas – and steam-based setup a possible functional environment for wind turbines with an alternative energy focus was established with the advent of the Mark V Series.

Hardware tips and specifications

The IS200VCRCH1BBC is a separate I/O board with the same functionality as the VCCC board. However, IS200VCRCH1BBC does not have a daughter board, while VCCC does. While this allows the IS200VCRCH1BBC to take up less rack space, the relay output must be routed through the J3 and J4 ports on the VME rack. If cabling on the front panel is not desirable, the recommended solution is to use a VCCC board instead of a VCRC board. The IS200VCRCH1BBC is connected to a single slot panel built with three LED indicators. These are labeled status, fail, and run, and are colored orange, red, and green. Two cable connectors (J33 and J44) are also located on the panel surface. The IS200VCRCH1BBC board is equipped with 6 connectors, including 2 backplanes. The board is densely packed with resistors, diodes, capacitors, inductive beads (L1-L19) and TP test points. It has more than 30 transistors and more than 60 integrated circuits on its surface. These include FPgas, CMOS static RAM, and dual-port SRAM. AX Control offers shipping options to suit your needs, whether you need to stay overnight or want to save money.
GE-FANUC IS200VCRCH1BBC - High-Performance Turbine Control System Module

Any hardware information stored above that is specific to the IS200VCRCH1BBC board is actually reminiscent of the diligent visual inspection of the IS200VCRCH1BBC printed circuit board product itself here, done by one of our experienced and meticulous PCB service technicians. This was considered necessary given the generally small number of Mark VI turbine control system series guidance documents available on the Internet after repeated copyright infringement cases. That being the case, the IS200VCRCH1BBC feature product number itself can also be a good primary source of IS200VCRCH1BBC Board hardware component and component specification information. Because it details many of the relevant IS200VCRCH1BBC Board details through a series of consecutive named elements. For example, this IS200VCRCH1BBC product number is started by including a dual-function IS200 series label, indirectly entrusting the normal Mark VI series components of this IS200VCRCH1BBC PCB and its domestic original manufacturing location. Some other relevant IS200VCRCH1BBC details revealed in this way include:

VCRC functional products for short
Conformal PCB coating style
The first group of Mark VI series groups
Triple revision history

2025-01-03 BY jonson

IN Industry trends

IS200VRTDH1DAB|VME resistance temperature detector card

IS200VRTDH1DAB is a GE Mark VI PCB component. Originally released by GE under the name “Speedtronic”, the Mark VI is one of a family of steam/gas turbine management systems designed to improve reliability and reduce downtime in heavy-duty turbines. The Mark VI is built with triple redundant backup on key controls and includes a central control module that connects to a PC-based HMI (Human machine interface). This interface allows access to fan data from one location using specially designed fan control software. The Mark VI turbine control system family to which the IS200VRTDH1DAB device belongs must be considered an attractive product family in the larger automation industrial market, as it was one of the last product families developed by GE, utilizing patented Speedtronic control system technology. The technology first appeared in the mid-to-late 1960s with the launch of the Mark I series. This IS200VRTDH1DAB device is not the original product of its specific Mark VI series features; This will be the IS200VRTDH1 parent VME resistance temperature detector card, utilizing two functional product versions and a single illustrated configuration version of the device.

Hardware tips and specifications

The IS200VRTDH1DAB excitations resistance temperature device (RTD) and captures the resulting signal and then converts it to a digital temperature value. These values are transmitted to the VCMI and controller via the VME backplane. RTD short and open circuits are detected by out-of-range values. These “out-of-hardware” RTDS are removed from the scanned input to prevent adverse effects on other input channels. These out-of-range RTDS can be manually restored or automatically restored every 20 seconds if they are in range. This IS200VRTDH1DAB device isn’t surrounded by a lot of original available instruction manual material online, as it belongs to a family of products that GE continually removes from the Internet for copyright purposes. While this is true, this IS200VRTDH1DAB device makes good use of its GE primary manufacturing, as it comes standard with an IS200VRTDH1DAB feature product number, delegating many hardware details in a series of feature naming segments. For example, the IS200VRTDH1DAB functional product number starts with a dual-function IS200 series label, which commissions the normal Mark VI series components of the IS200VRTDH1DAB product and its domestic original manufacturing location. Some other related hardware details embedded in this feature product number include IS200VRTDH1DAB PCB:

VRTD Function product number
Conformal PCB coating style
The first group of Mark VI series products
Triple revision history
The front panel is connected to the IS200VRTDH1DAB by three screws; This front panel appears to indicate the position of the IS200VRTDH1DAB product in the standard VME rack-mount assembly of the standard Mark VI turbine control system family. The base printed circuit board of the IS200VRTDH1DAB product ensures voltage protection in a standard style through a series of standardized selection of voltage limiting hardware components and component specifications. The back of the board is filled with two backplane connectors. The IS200VRTDH1DAB has more than 200 integrated circuits, more than 200 capacitors and hundreds of resistors.

2025-01-03 BY jonson

IN Industry trends

IS200VSVOH1BDC|Mark VI turbine control system series manufacturing

This GE IS200VSVOH1BDC printed circuit board product was originally designed and produced for the mark VI family of turbine control systems, as described in the GE guidance manual material provided with the product above. The Mark VI family of fan control systems, as evidenced in part by its full extended family name, has a range of application-specific options in gas, steam and wind turbine automatic drive components. That being said, it still has to be considered individually to be attractive in the larger image automation industrial community, as it was one of the GE Mark product families eventually developed by GE, and it utilizes Speedtronic control system technology, which was first released to the community. With the success of the original Mark I series in the mid-to-late 1960s.

Hardware tips and specifications

The servo control card IS200VSVOH1BDC is designed for use with servo valve interface applications for I/O or pulse rate (speed) input. When used with pulse rate inputs, the VSVO card is used for shunt feedback in the servo loop. Pulse rate inputs do have a specific frequency range, i.e. 2 to 14,000 Hertz. Another feature of the VSVO card when used with pulse rate input is the interface of the speed sensor, the two sensor types of the interface are passive or active. The card can also support two more passive speed sensors, as long as it is used with a backup protection module. Before considering a final purchase of this IS200VSVOH1BDC product, it is most important to realize that the performance specifications and dimensions that were originally introduced have undoubtedly changed by accepting the full triple product revision history, This includes Level B major IS200VSVOH1BDC board functional product revisions, Level D secondary IS200VSVOH1BDC board functional product revisions, and last but not least, level C graphic configuration revisions that change the location of individual hardware components on the base printed circuit board of the IS200VSVOH1BDC device.
GE IS200VSVOH1BDC: Precision Servo Control Board for Industrial Automation

As mentioned above, the IS200VSVOH1BDC card will use the servo valve interface I/O. When the VSVO uses this feature, a number of features are available, some of which are selectable current drivers, feedback from the LVDR, the LVDT, and pulse rate inputs from the shunt feedback. The VSVO card can also be used with two or three coil servos, depending on the redundancy application chosen. VSVO cards typically use four servo channels, each of which can use up to three LVDT/LVDR feedback sensors, as well as a median, high or low selection manufactured in the software. Please note that the servo current output used in this model will be bi-directional. When the IS200VSVOH1BDC model is used for TMR applications, it is recommended to use at least two LVDTS/LVDRS, as each sensor requires an AC excitation source. The relevant manuals used with this model are the GER-4193A Speedtronic Mark VI System Guide or the GEH-6421C Volume II System Guide. Given that this IS200VSVOH1BDC product is part of the now discontinued legacy GE product family, the IS200VSVOH1BDC functional product number itself can actually be used as an important primary source of IS200VSVOH1BDC Board hardware component and component specification information; Encode various relevant details in multiple functional naming segments designed by GE. For example, the IS200VSVOH1BDC functional product number starts with a dual-function IS200 series label, which is responsible for indirectly stating the normal Mark VI series assembly version of the IS200VSVOH1BDC product and its standard domestic original manufacturing location.

2025-01-03 BY jonson

IN Industry trends

IS200VTCCH1CBB|Thermocouple terminal board

The GE IS200VTCCH1CBB printed circuit board product was originally designed and manufactured specifically for placement in the Mark VI family of turbine control systems, as described in the specification manual materials initially available for the IS200VTCCH1CBB thermocouple terminal board product. This IS200VTCCH1CBB thermocouple terminal board product belongs to the Mark VI family of turbine control systems, as you are likely to infer only from its full extended family name, especially as it relates to control systems and management systems for GE compatible gas, steam and wind turbine automation drive components. This expected range of functional applications is actually seen as an upgrade over the previous Mark V family of turbine control systems of the same name, as the Mark V family only has a more limited set of functional Settings applications in steam and gas turbine control systems. In this context, the larger Mark VI series of IS200VTCCH1CBB thermocouple terminal boards alone is an attractive GE product family in the larger automation industrial market, as it is one of the final GE logo product families developed. Integration of patented Speedtronic control system technology into a range of different products.
GE IS200VTCCH1CBB - Conformally Coated PCB Board for Mark VI Speedtronic Systems

Hardware tips and specifications

Model IS200VTCCH1CBB is one of the Mark VI boards produced by General Electric. This model is designated as a thermocouple input and can accept up to 24 thermocouple inputs. This type of input can be connected to a DTTC or TBTC terminal board. The TBTC terminal board is a related terminal board, while the DTTC board is a DIN European size terminal board. Depending on the TBTC model used with the VTCC model, it can be used in two different groups. The TBTCH1C model allows simplex control, while the TBTCH1B model allows triple modular redundancy (TMR) control. There are also two sets of VTCC models; The IS200VTCCH1CBB model is part of the first group, which shows that the model can be used with gas turbine control applications. Regardless of which group the VTCC model is used in, the same terminal board will be used. Since this IS200VTCCH1CBB thermocouple terminal board product belongs to the Mark VI series, it is not surrounded by many online instruction manual materials. In this case, the IS200VTCCH1CBB functional product number of the IS200VTCCH1CBB thermocouple terminal board itself can be a powerful source of information about the hardware components and component specifications of the IS200VTCCH1CBB board. Because it encodes many of the relevant IS200VTCCH1CBB board details through feature selection of its functionally named elements. F or example, the IS200VTCCH1CBB Functional product number begins with an iteration of a dual-function IS200 series label that delegates the normal Mark VI series component of this IS200VTCCH1CBB product to the top of its domestic original manufacturing location. Some of the other related hardware specifications revealed in this way include the following for this IS200VTCCH1CBB product:

VTCC Functional Products acronym
The first group of Mark VI series products
Conformal PCB coating style
Triple revision history
While the IS200VTCCH1CBB model accepts thermocouple inputs, the VTCCH1 model supports input types E, J, K, S, and T thermocouples and mV inputs. VTCC models allow a range of mV from -8 mV to +45 mV. The thermocouple inputs used with this model can be grounded or ungrounded and can be located up to 984 feet from the relevant turbine control cabinet. Two cold junctions and high-frequency noise suppression devices are installed on the terminal board. When the IS200VTCCH1CBB model is running in a TMR system, if a signal on the device changes from the median/voting value beyond a predetermined limit, the signal will be identified and cause a fault. For more information on fault indications and available diagnostic tests for VTCC models, see GE manual GEH-6421.

2025-01-03 BY jonson

IN Industry trends

IS200VTURH2BAC|Manufactured by the Mark VI series of turbine control systems

IS200VTURH2B is a PCB component manufactured by GE for the Mark VI system. Mark VI is a steam/gas turbine management system created and released by General Electric as part of its “Speedtronic” family. It was one of the last Speedtronic systems to be released by GE, and one of the most technologically advanced. Mark VI includes fully programmable software maintenance tools provided in the system HMI (Human Machine Interface). The Mark VI family of turbine control systems that encapsulate this IS200VTURH2B unit is known to have a specific range of possible functional applications in GE compatible systems for the management and control of automatic drive components for gas, steam and wind turbines. Given that the Mark VI series will likely apply alternative energy based wind turbines to the gas turbine and steam turbine possible environments built through the Mark V, this must be identified as a large-scale functional upgrade of the previous industry standard Mark V turbine control system family, more or less with the same full extended series name. The Mark VI series of this IS200VTURH2B device is one of the final released iterations of the GE Mark product family powered by Speedtronic control system technology and therefore receives additional attention.
GE IS200VTURH2BAC - Turbine Protection Circuit Board

Hardware tips and specifications

As a main turbine protection board, the IS200VTURH2B has a variety of functions, including monitoring the shaft and voltage and current, as well as (in gas turbine applications) monitoring the Geiger-Mueller flame detector. The board monitors 4-speed inputs from passive magnetic sensors to maintain these functions. Flame detectors help determine if carbon deposits or other contaminants are reducing light detection within the system. The PCB can also issue trip commands in turbines without mechanical overspeed bolts. The IS200VTURH2B is made of double-wide panels. This panel has very few components, but it does have three LED indicators and cable connectors. The panel is attached to the edge of the front panel by three screws. The IS200VTURH2B has two backplane connectors and other connectors. It has 13 transistors, inductors, resistors and capacitors on both the front and back of the board. The board consists of an auxiliary board connected by four brackets, which have an additional back plate. The board has integrated circuits, including SRAM and RAM chips, oscillating chips, and FPGas.

For more information about the IS200VTURH2B board, please refer to several GE publications, including the Mark VI Control System Guide GER-4193A and GEH-6421. Unfortunately, given that the Mark VI series faced a series of repeated copyright infringements in the years following its initial release, many of these originally relevant guidebook materials have been removed from their original online resources. While that may be the case, this IS200VTURH2B product still benefits greatly from its original General Electric design and manufacture in another way, as it is given the IS200VTURH2B functional product number, Many of the relevant IS200VTURH2B Board details are indirectly asserted through a series of successive functional naming elements. For example, this IS200VTURH2B model specifically begins by including a dual-function IS200 Series label, indirectly declaring that the IS200VTURH2B device is a normal Mark VI series component above its original manufacturing location in the country. Some other fascinating IS200VTURH2B board qualities revealed through this medium include:

VTUR Functional Products acronym
Group 2 Mark VI series grouping
Conformal PCB coating style
Class B Functional Product revision
