Model:3HNA023093-001
Manufacturer:ABB
Type:Thermocouple/MV Input Module
Temperature Measurement Range:-200°C to +1800°C
Voltage Measurement Range:0 to 100V
Accuracy:+/- 0.5% of reading
Input Resistance:3.3kΩ
Supply Voltage:DC 24V
Current Consumption:Typically less than 5mA
Communication Interface:Modbus RTU
Environmental Conditions:Operating: -25°C to +55°C, Storage: -40°C to +85°C
Dimensions:200mm x 100mm x 30mm
Weight:0.4kg
The ABB 3HNA023093-001 Thermocouple/MV Input Module is engineered with high precision and reliability, making it ideal for integrating into complex industrial automation systems. It seamlessly connects to various industrial control platforms, providing seamless integration and data exchange.
With a wide operating temperature range from -200°C to +1600°C, this module ensures accurate temperature measurements in extreme environments. Its dual input capability supports both thermocouple signals and voltage inputs, catering to a broad spectrum of industrial applications.
Featuring exceptional accuracy, the ABB 3HNA023093-001 module ensures reliable data acquisition, crucial for process control and monitoring. Its 0.01°C resolution and ±0.5% of reading or ±2°C accuracy make it a preferred choice for applications requiring high precision.
Powerful yet efficient, the module operates on a DC 24V supply, consuming up to 35mA, making it suitable for various power scenarios in industrial settings. Its compact dimensions (140mm x 70mm x 35mm) and lightweight design (approx. 120g) facilitate easy installation and maintenance.
The robust construction and IP65 protection rating of the ABB 3HNA023093-001 module ensure durability and protection against dust and water ingress, essential for industrial environments. It is compatible with industry-standard protocols, ensuring seamless integration with existing control systems.
