Type:IGBT Module
Model Number:5SHX 1000H0003
Power Rating:1000 kW
Operating Temperature Range:-40°C to +125°C
Insulation Class:180°C
Cooling Method:Thermal Conduction
Input Voltage Range:DC 1500 V
Output Current:Up to 2000 A
Package Type:Standard IGBT Module
Mounting Method:Panel Mount
Material:Aluminum Alloy
The ABB 5SHX 1000H0003 IGBT Module boasts an innovative design that combines high efficiency with reliability, making it ideal for demanding industrial environments. This module is engineered with cutting-edge technology, offering superior switching performance and exceptional thermal management capabilities.
Engineered for durability, this IGBT module operates within a wide temperature range, from -40°C to +175°C, ensuring continuous performance in even the most extreme conditions. Its water-cooled system optimizes heat dissipation, enhancing its operational life and efficiency.
With a power rating of 1000 kW, this module is capable of handling significant power demands, making it suitable for large-scale industrial applications. The compact size of the module allows for seamless integration into existing systems without compromising on space or performance.
Featuring an insulation class H, the module ensures robust electrical isolation, safeguarding against potential failures and ensuring the safety of personnel and equipment. The high input voltage capability of 380 V AC makes it compatible with a wide range of industrial power sources.
The ABB 5SHX 1000H0003 IGBT Module stands out for its advanced switching frequency of up to 15 kHz, enabling precise control and improved power conversion efficiency. This feature is particularly beneficial in applications requiring fast response times and high performance.
