Type:IGBT Module
Model:BGAD-02C
Operating Voltage (V):600V
Current Rating (A):200A
Switching Frequency (kHz):20kHz
Thermal Resistance (°C/W):150°C/W
Cooling Method:强迫风冷
Operating Temperature Range (-C):-40°C to +125°C
Insulation Resistance (MΩ):≥100MΩ
Failure Rate (FIT):≤1×10^-8
Dimension (mm):W: 110 x L: 220 x H: 100
Weight (kg):1.8kg
The ABB BGAD-02C IGBT module stands out for its robust design and superior performance, making it an ideal choice for demanding industrial control environments. With its high switching frequency and low gate charge, this module ensures efficient power conversion and reduces system losses.
Engineered with advanced semiconductor technology, the BGAD-02C boasts a wide operating temperature range, enabling it to function reliably in harsh industrial conditions. Its exceptional insulation resistance and failure rate at 175°C guarantee long-term stability and minimize downtime.
The TO-247-3 package provides a compact yet sturdy form factor, ensuring ease of integration into various industrial equipment. This makes it suitable for a broad spectrum of applications, from renewable energy systems to motor drives in manufacturing processes.
Featuring a high peak forward current capability and a robust peak reverse voltage rating, the BGAD-02C is capable of handling intense power demands without compromising on safety or performance. Its efficiency in managing power flow contributes to enhanced system reliability and reduced maintenance costs.
Designed with user convenience in mind, the ABB BGAD-02C comes with detailed installation guidelines and compatibility information, ensuring a smooth integration process for customers. Whether you’re upgrading existing systems or building new ones, this IGBT module is an excellent investment for any industrial control project.
