Power Rating:120kW
Operating Voltage:DC 250V
Frequency Range:0Hz to 6kHz
Switching Frequency:20kHz
Cooling Method:Air Cooled
Dimensions (LxWxH):250mm x 120mm x 45mm
Weight:2kg
Temperature Range:-20°C to +70°C
Input Current:160A
Output Current:320A
Insulation Class:F
Protection Level:IP20
The ABB NINT-45C BSM25GD120DN2 IGBT Module is engineered for demanding industrial environments, offering unparalleled power handling capabilities and exceptional thermal management.
This high-performance module is specifically designed to enhance the efficiency and reliability of drive systems, renewable energy solutions, and electric vehicles.
Featuring an advanced TO-247 package, the NINT-45C ensures optimal heat dissipation and long-term durability under extreme operating conditions.
With its robust insulation class and compliance to international electrical standards, the module guarantees safety and compatibility across various global applications.
Ideal for applications requiring precise control and high efficiency, the ABB NINT-45C BSM25GD120DN2 IGBT Module provides unparalleled performance, making it a preferred choice for engineers seeking cutting-edge technology in high-power electronics.
