ABB PM152 3BSE003643R1 – Analog Output Module, Precision & Reliability in Control Systems

Manufacturer:ABB

Model Number:PM152 3BSE003643R1

Module Type:Analog Output

Output Channels:1

Voltage Rating:DC 24V

Current Output Range:0 to 20mA

Accuracy:+/- 1% FS

Response Time:Less than 1ms

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

Reliability:MTBF > 100,000 hours

Communication Interface:MODBUS RTU

Dimensions:114mm x 114mm x 114mm

Weight:0.5kg

Mounting:Panel Mount

IP Rating:IP20

Certifications:CE, UL, CSA, TUV

    The ABB PM152 3BSE003643R1 Analog Output Module is engineered with precision and reliability at its core, ensuring seamless integration into complex industrial automation systems. This module is specifically designed to handle the conversion of digital signals into analog signals, delivering unparalleled accuracy and consistency.

    Featuring a wide operating voltage range of 220V, it is compatible with various power sources commonly found in industrial environments. Its adjustable analog output range can be configured to 0-10V or 4-20mA, catering to diverse application requirements.

    With a resolution of 0.01% of full scale, this module ensures that even minute changes in input are accurately reflected in the output, providing users with precise control over their processes. Its accuracy is further enhanced by a specified error margin of +/- 0.02% of full scale, making it an indispensable component in critical systems.

    Operating within a temperature range of -20°C to +60°C, the ABB PM152 3BSE003643R1 is designed to withstand harsh industrial conditions without compromising performance. Additionally, its low power consumption ensures efficient energy use, reducing operational costs and environmental impact.

    Equipped with MODBUS RTU communication protocol, this module facilitates easy connectivity with other devices in the system, enabling seamless data exchange and control. Whether you’re managing production lines, monitoring process parameters, or controlling machinery, the ABB PM152 3BSE003643R1 is your trusted partner for achieving optimal control and efficiency in your operations.
