Input Voltage Range:100-240V AC
Operating Frequency:47-63Hz
Peak Output Current:7.5A
Torque Range:0.34-50.8Nm
Maximum Output Current Flow:500mA
SERCOS Interface Compatibility:Yes
Machine Control Architectures Supported:SLC, Logix Devices
Ambient Temperature Range:-40°C to 70°C
Relative Humidity Range:5% to 95%
Fuse Type Recommended:FNQ-R-30
Environmental Protection:IP20 Enclosure
Integrating advanced technology, the Allen-Bradley 1398-DDM-075 Servo Drive Module offers unparalleled performance for demanding industrial environments. Its built-in microprocessor ensures fast and accurate feedback signal processing, enhancing system responsiveness and stability.
This servo drive is equipped with a variety of terminal strips for easy installation of passive shunt resistor, motor power connections, DC bus voltage, and AC input power connections, streamlining the setup process for various applications.
With its compact design and robust construction, the 1398-DDM-075 is designed to withstand harsh industrial conditions while delivering precise control. It supports a wide range of machine control architectures, making it compatible with leading control systems like SLC and Logix devices.
Featuring an internal shunt resistance of 16.5 Amps and 4290 µF bus capacitance, the drive ensures stable operation under varying loads and speeds. The 452 Volt DC bus overvoltage value provides added safety margins for critical applications.
For optimal performance, it is recommended to operate the drive within specified ambient temperature and humidity ranges. Proper installation in a grounded cabinet can further enhance its reliability and longevity, ensuring minimal downtime and maximum productivity.
