Number of Channels:4
Input Range:-20 to 20 mA
Common Mode Voltage Range:-20 to 20 V
Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Input Range for DC Voltage:-10 to 10 VDC – 1 LSB
Current Rating:Backplane Current Draw: 35 MA at 5 V, 85 MA at 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The 1746-INT4 Analog Input Module is a robust component designed for seamless integration into a wide range of industrial control systems. Its ability to accurately measure and transmit voltage and current signals makes it an indispensable tool for real-time data monitoring and control.
Each of the four channels is equipped with advanced signal conditioning circuits, ensuring reliable operation under varying environmental conditions. The module supports both voltage and current inputs, providing flexibility for different applications.
With a sampling rate of up to 100 samples per second, this module ensures minimal latency in data acquisition, crucial for dynamic processes that require immediate feedback. This feature is particularly beneficial in industries where precise timing can significantly impact efficiency and safety.
Engineered for industrial use, the 1746-INT4 is designed to withstand harsh operating environments, from freezing cold to scorching hot conditions. Its panel-mount design ensures easy installation and integration into existing control panels.
The module’s low power consumption and wide operating voltage range make it an energy-efficient choice, reducing operational costs and enhancing system reliability. Additionally, its compatibility with RS-485 communication protocols allows for seamless integration with a variety of PLCs and other control devices, facilitating a comprehensive automation solution.
