Allen-Bradley 1756-IF16 ControlLogix 16 Pt A/I Module

Model Type:High Capacity IP Module

Model Number:1756IF16

Manufacturer:Allen-Bradley

Weight:0.50 lbs

I/O Capacity:16 Points

Analog Input Capacity:Single-ended or differential

Communication Speed:10/100 Mbps

Enclosure Type:Open Type

Environmental Conditions:Temperature: 0 – 60 DEG C, Humidity: 5 – 95% Non-Condensing

Power Dissipation:5.1 W

Isolation:30 V Continuous

Connection:Ethernet/IP Bridge

Cable Compatibility:802.3 Compliant Shielded Or Unshielded Twisted Pair

    The Allen-Bradley 1756-IF16 ControlLogix 16 Pt A/I Module is specifically engineered for applications requiring precise and reliable analog input data acquisition. It supports multiple data formats, allowing for flexibility in interfacing with various industrial systems.

    This module boasts an impressive capacity of 16 points, which can be configured as either single-ended inputs or differential inputs, catering to a wide array of measurement needs. It includes advanced features like real-time sampling and under/over-range detection, ensuring accurate and timely data transmission.

    Designed for seamless integration into ControlLogix systems, this module leverages HART communication technology, enabling efficient setup and monitoring through intuitive graphical user interfaces. Its fast data transfer speed ensures smooth operation within complex industrial environments.

    The robust construction of the Allen-Bradley 1756-IF16 Module withstands harsh industrial conditions, from extreme temperatures to high humidity levels, guaranteeing reliable performance in diverse settings. Its power consumption is optimized to ensure energy efficiency without compromising functionality.

    With its comprehensive feature set and durable design, the Allen-Bradley 1756-IF16 ControlLogix 16 Pt A/I Module is an ideal choice for enhancing the accuracy and efficiency of industrial automation processes.
