GE 369-HI-R-M-0-0-0-0 – Motor Management Relay with Built-in Metering and RTD Inputs

Control Power Nominal:20 VA

Control Power Maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:Class I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Weight:approx. 4.5 kg

Optional Metering Feature:Included

RTD Inputs:12 built-in

Communication Ports:Non-isolated RS232 port, RS485 port

Differential Switch Time Delay:<200 ms

Event Record Triggers:Power fail, alarms, self test, inhibit, trip, waveform capture

Operating Range:-40°C (-40°F) to +60°C (140°F)

Storage Range:-40°C (-40°F) to +80°C (176°F)

    The GE 369-HI-R-M-0-0-0 Motor Management Relay is designed to optimize the performance and reliability of medium-sized motors. Featuring waveform capture technology, this relay captures detailed information about the motor’s operational status, which can be analyzed to identify potential issues before they lead to costly downtime. With built-in event reporting and data logging, users can maintain comprehensive records of motor performance and system health.

    This model includes optional metering capabilities, allowing for precise measurement of electrical parameters such as voltage, current, and power factor. Additionally, the inclusion of twelve RTD (Resistance Temperature Detector) inputs provides accurate temperature monitoring of critical motor components, further enhancing overall system safety and efficiency.

    The compact design of the GE 369-HI-R-M-0-0-0 ensures easy integration into existing industrial control systems without requiring extensive space modifications. Its robust construction and insulation class I rating make it suitable for harsh industrial environments, ensuring reliable operation under varying conditions.

    In summary, the GE 369-HI-R-M-0-0-0 Motor Management Relay is a powerful tool for any facility looking to streamline their motor management processes. With its advanced monitoring and protection features, it delivers unparalleled reliability and cost savings.
