Baud Rate:300 to 19200 baud
Frequency Range:25 to 60 Hz nominal
Humidity Tolerance:Up to 90% non-condensing
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Relay Dimensions:Approx. 18cm W x 16.5cm L x 21.5cm H
Current Inputs:5 A phase current inputs and 1 A zero sequence current inputs
Voltage Inputs:3 voltage inputs
Logic Input States:14 logic input states
Output Relays:8 output relays
Insulation Voltage:300 V
The GE SR750-P5-G1-S1-HI-A20-R is an advanced feeder management relay designed to provide reliable control and protection for distribution systems. This relay boasts multiple current and voltage channels, enabling comprehensive waveform capture and analysis. Its modular design allows for flexible installation, either individually or alongside other GE 750 series units. The device supports communication protocols like Modbus RTU and DNP 3.0, making it easy to integrate into existing systems. With features such as overcurrent protection, under/overfrequency protection, and ground fault protection, this relay ensures robust performance and safety. The relay is built to withstand harsh operating environments, with humidity tolerance up to 90% non-condensing. Its compact dimensions make it suitable for panel mounting in various settings.
