General Electric 169-100P-120 Motor Management Relay

Manufacturer:General Electric Multilin (GE)

Manufacturing Location:Markham, Ontario, Canada

Model Number:169-100P-120

Maximum Operating Current:10 Amps

Minimum Permissible Load:5 VDC, 100 mA

RTD Trip/Alarm Setpoint Range:0 to 200°C

Display Operational Range:0°C to +55°C

Operating Temperature Range:–10°C to +60°C

Phase Current Input Range:0.05 to 12 × phase CT primary amps setpoint

Software:EnerVista 169

    The General Electric 169-100P-120 Motor Management Relay offers unparalleled reliability and precision in the control and safeguarding of electric motors in industrial settings. Designed with advanced technology, it features a robust construction capable of withstanding harsh environments, ensuring continuous operation even under challenging conditions. Its RTD trip/alarm function allows for precise temperature monitoring, while its wide phase current input range makes it versatile enough to suit various applications.

    This relay provides comprehensive protection by monitoring for overcurrent, phase imbalance, and other potential threats to motor health, alerting operators through clear indicators and alarms when action is needed. With a user-friendly display that operates within a broad operational range, the 169-100P-120 ensures easy monitoring and maintenance.

    Key Features:

    – Maximum Operating Current: Up to 10 Amps for enhanced performance.

    – High RTD Trip/Alarm Setpoint Range: Monitors temperatures from 0 to 200°C accurately.

    – Wide Phase Current Input Range: Suitable for a variety of industrial motor sizes.

    – User-Friendly Interface: Simplifies operation and maintenance with an intuitive display.

    Designed for integration into existing systems, this relay supports seamless connectivity with its software compatibility and robust construction, making it an essential component for any industrial facility looking to enhance motor protection and efficiency.
