I/O Size:16-bit integers
Communication Parameters:Baud Rate: 110 to 115K baud, Stop Bits: 1 or 2, Data size: 7 or 8 Bits, Parity: None, Even, Odd
Floating Point Data:Support for floating point data movement
Extended Features:Up to 5000 registers storage and transfer using block transfer interface, configurable for Enron, Daniel® and other implementations
Memory Usage:User-definable module memory
Ethernet Compatibility:10/100 Base-T Ethernet interface
Data Mapping:Starts at Modbus register 40001
Response Delay:Configurable from 0 to 65535 milliseconds
Compatibility:ASCII protocol
Module Type:Modbus TCP/IP Multi-Client
The Prosoft MVI69-MNETC Communication Module is engineered for seamless integration within industrial control systems. Its advanced features allow for the efficient transfer of data between PLCs and external devices, enhancing productivity and system reliability.
Featuring a compact design and high-speed 10/100 Base-T Ethernet interface, this module ensures fast and reliable data transmission over a Modbus TCP/IP network. The user-definable memory usage and configurable parameters offer flexibility to tailor the module to specific application requirements.
Support for up to 5000 registers facilitates extensive data handling, enabling complex operations and data-intensive applications in various industries. The ability to start all data mapping from Modbus register 40001 simplifies integration with existing systems.
Enhanced with floating-point support for popular implementations like Enron and Daniels®, the MVI69-MNETC ensures compatibility and precision in calculations and data processing. Its robust error handling mechanism eliminates the need for deciphering cryptic error or alarm codes, streamlining troubleshooting and maintenance processes.
For disaster recovery scenarios, the module incorporates a non-volatile industrial-grade Compact Flash (CF) card. This allows for easy backup and quick field replacement of the module, minimizing downtime and maximizing operational efficiency. The PDS software further aids in locating the module on the network and assigning a temporary IP address, streamlining setup and management tasks.
