Frequency Range:0.001 Hz to 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Noise, Arbitrary
Output Amplitude:±10 Vpp (50 Ω), ±20 Vpp (Open)
Resolution:14 bits
Phase Shift:0 to 360 degrees
Synchronization:Internal/External Triggering
The Tektronix 5A18N Arbitrary Function Generator provides unparalleled precision and flexibility for waveform generation. With its advanced digital signal processing capabilities, this generator can simulate complex signals with ease.
This model features two independent output channels, allowing users to generate synchronized or independent waveforms for comprehensive signal analysis and testing.
The generator supports a wide range of waveform types including sine, square, triangle, ramp, pulse, and arbitrary waveforms up to 32k points long. This versatility makes it ideal for a variety of applications.
The high sampling rate of 125 MSa/s ensures smooth and accurate waveform reproduction, while the 16-bit vertical resolution delivers exceptional clarity and detail in the generated signals.
Additional features such as phase shift control, multiple trigger modes, and built-in waveforms make the Tektronix 5A18N a robust tool for engineers and researchers looking to perform detailed signal analysis and testing.
