Connection Technology:Field supply
Operating Temperature Range:-40 … 85 °C
Storage Temperature Range:-40 … 85 °C
Relative Air Humidity:95 % (no condensation)
Environmental Exposure:Per IEC 60068-2-42 and IEC 60068-2-43
Power Supply Voltage:DC 24 V (-25 … 30 %); via wiring level (CAGE CLAMP®connection)
System Supply Voltage:DC 5 V; via data contacts
Transmission Channels:RS-422 / RS-485
Data Bits:7/8, adjustable
Stop Bits:1/2, adjustable
Supply Voltage (System):DC 5 V; via data contacts
Power Consumption:65 mA (5 V system supply)
Width:12 mm / 0.472 inch
Height:69.8 mm / 2.748 inch
Height from Upper-edge of DIN-35 Rail:62.6 mm / 2.465 inch
Depth:100 mm / 3.937 inch
Material:Polycarbonate, polyamide 6.6
Color:Light Gray
Weight:32.298 g
Conformity Marking:CE
The WAGO 750-602 Power Supply Module is designed for seamless integration into complex industrial environments, ensuring reliable power distribution. Its compact, modular design allows for easy installation and maintenance.
Equipped with advanced field supply technology, this module ensures stable power delivery across various components, enhancing operational efficiency and system reliability.
Featuring an operating temperature range of 0 to 55 degrees Celsius and exceptional humidity tolerance, the 750-602 is engineered to withstand harsh industrial conditions, providing continuous performance under diverse environmental challenges.
With its light gray housing made from durable polycarbonate and polyamide 6.6, the module not only meets industrial standards but also integrates aesthetically with modern control panels.
The WAGO 750-602 comes with a CE conformity marking, guaranteeing compliance with European safety and quality regulations. It is a testament to WAGO’s commitment to delivering high-quality, reliable solutions that meet the stringent requirements of industrial automation.
